MERAKI MX-64

100% Cloud Managed

Networking and Security

Hardware

  • Stateful firewall throughput: 250 Mbps
  • Recommended maximum clients: 50
  • Small form factor

Cloud-based Centralized Management

  • Managed centrally over the web
  • Classifies applications, users and devices
  • Zero-touch, self-provisioning deployments

    Networking and Security

    • Stateful firewall
    • Auto VPN self-configuring site-to-site VPN
    • Active Directory integration
    • Identity-based policies
    • Client VPN (IPsec)
    • 3G / 4G failover via USB modem

    Traffic Shaping and Application Management

    • Layer 7 application visibility and traffic shaping
    • Application prioritization

    MX-64

    Network and Security Services

    • Stateful firewall, 1:1 NAT, DHCP, DMZ, static routing
    • Identity-based policies
    • Auto VPN self-configuring site-to-site VPN
    • Client VPN (IPsec)
    • User and device quarantine
    • VLAN support and DHCP service

    Advanced Security Services

    • Content filtering (Webroot BrightCloud CIPA-compliant URL database)
    • Web search filtering (including Google and Bing SafeSearch)
    • YouTube for schools
    • Intrusion prevention (Source Fire Snort based)
    • Antivirus and antiphishing filtering
    • Standard and Affordable IP Phone with optional
    • Requires Advanced Security License

    WAN Performance Management

    • WAN link aggregation
    • Application level (Layer 7) traffic analysis and shaping
    • Automatic Layer 3 failover (including VPN connections)
    • WAN uplink selection based on traffic type

    Monitoring and Management

    • Web-based management and configuration
    • Throughput, connectivity monitoring and alerts
    • Network asset discovery and user identification
    • Built-in network-wide reporting, monitoring and alerts
    • Centralized policy management
    • Real-time diagnostic and troubleshooting over the web
    • Automatic firmware upgrades and security patches
    • Searchable network-wide event logs

    Interfaces

    • WAN: 1 × 1 GbE
    • LAN: 4 × 1 GbE (1 optionally available for WAN connectivity)
    • USB: 1 × USB 2.0 for 3G/4G failover (supported devices)

    Performance

    • Stateful firewall throughput: 250 Mbps
    • VPN throughput: 100 Mbps
    • Recommended for small branches (up to 50 users)

    Power

    • Single 18W power supply

    Environment

    • Operating temperature: 32°F to 104°F (0°C to 40°C)
    • Humidity: 5 to 95% non-condensing
